Ingersoll Rand C Series Manual Ratchet Puller // Come Along
$315.00
| MODELNAME | C400H | C400S |
|---|---|---|
| Headroom, in (mm) | 22.0 (558.8) | 22.0 (558.8) |
| Pull to Lift Rated Load, lbs (kg) | 62 (28.2) | 70 (31.8) |
| Shipping Weight, lbs (kg) | 16 (7.3) | 16 (7.3) |
| Capacity, lbs (kg) | 3400 (1545) | 4000 (1818) |
| No. of lines | Single | Single |
-
Cable Puller: 4:1 design factor for lifting, lowering and pulling. Meets Specifications - Overload safety handle is designed to deform when capacity rating is exceeded - Lightweight aluminum frame - Alloy steel load hook with safety latches - One piece cast aluminum drum - Buttress tooth design improves load gear life - Solid steel drive and holding dog, not laminated plates - Galvanized aircraft-quality wire rope - Ratchet and pawl system provides safe, one-notch-at-a-time lowering - Cable guide and shield protects wire rope and spools cable evenly on drum - Reversible handle changes position easily, so pull is always possible in the right direction, against the load - Easy to repair, replacement parts available - Plated external parts for corrosion resistance
-
Strap Puller: All the features of our popular C Series, plus the following unique features: - Three hooks allow 2 ton capacity; 6 foot pull with double line and 1 ton capacity with 12 foot pull using single line - Non-conductive, corrosion resistant, high strength synthetic strap will not kink or bind - Easy pay-out of strap for fast set-up
